P2P-KDT300

Become a dealer

Point to Point | Single-Head | DisplayPort CAT5 | Fiber Transmitter | USB 2.0 | Audio | Optional RS-232

Extend, control, and manage your DP-based workstation over IP with the P2P-KDT300. Supporting flexible Direct, Matrix, and SaviGate modes, the P2P-KDT300 adapts to your installation needs — from simple point-to-point extensions to full multi-user managed environments — over CATx or Fiber.

  • SUPPORTS DVI VIDEO UP TO 4K @ 30HZ OR 1080P @ 60HZ

  • TRANSPARENT USB 2.0 EXTENSION FOR PERIPHERALS

  • ANALOG AUDIO AND RS-232 PASSTHROUGH

  • SELECTABLE DIRECT, MATRIX, AND SAVIGATE MODES VIA WEB INTERFACE

  • SAVIGATE GATEWAY SUPPORT FOR CENTRALIZED MANAGEMENT (SOLD SEPARATELY)

  • UP TO 100M OVER CATX / 10KM OVER FIBER

  • ULTRA-LOW LATENCY JPEG2000 COMPRESSION

  • PLUG-AND-PLAY INSTALLATION

  • EDID LEARNING AND MANAGEMENT

  • AV AND IT EXTENSION FOR SECURE ENVIRONMENTS

  • BROADCAST AND PRODUCTION CONTROL ROOMS

  • MILITARY AND GOVERNMENT OPERATIONS

  • MEDICAL AND INDUSTRIAL COMMAND CENTERS

  • DIGITAL SIGNAGE AND WORKSPACE CENTRALIZATION

Video OUT

  • Format: DisplayPort 1.2 Compliant, Video Bandwidth Up To 17.28 Gbps

  • Video Resolution: Up To 4K @ 30 Hz, WQXGA @ 60 Hz

  • Connector: 1× DisplayPort (20-Pin Female)

Other

  • Power: 12 V DC, 3 A (Power Supply Included)

  • Reliability (MTBF): 135,540 Hours (MIL-HDBK-217F (N2) Parts Count Prediction Calculator)

  • Environmental Operating Temperature: 0°C to 45°C (32°F to 113°F)

  • Environmental Operating Humidity: 10% to 90%, non-condensing

  • ESD Protection: Protection per IEC 61000-4-2 Standard at ±30 kV Air and ±30 kV Contact

  • Support Warranty: 1-Year

  • Certification: CE, FCC, RCM, UL

  • Dimensions: 9.5″W × 5.25″D × 1.70″H

  • Weight: 1.41 lbs (0.63 kg)

P2P-KDR300-S

Point-to-point Dual-Head DP CAT5 & Fiber Receiver with USB 2.0, Audio and RS-232
[Includes: P2P-KDR300, PS12VD3A]
