P2P-KVR302

Become a dealer

Point to Point | Dual-Head | DVI CAT5 | Fiber Receiver | USB 2.0 | Audio | Optional RS-232

P2PKVR Series High-Performance KVM-over-IP Extender & Matrix Solution. Designed for mission critical environments, it delivers ultra-low latency, dual DVI video, and secure connectivity over CAT5 and Fiber networks, ensuring efficient system control and flexibility.

  • SUPPORTS DVI VIDEO UP TO 4K @ 30HZ OR 1080P @ 60HZ

  • TRANSPARENT USB 2.0 EXTENSION FOR PERIPHERALS

  • ANALOG AUDIO AND RS-232 PASSTHROUGH

  • SELECTABLE DIRECT, MATRIX, AND SAVIGATE MODES VIA WEB INTERFACE

  • SAVIGATE GATEWAY SUPPORT FOR CENTRALIZED MANAGEMENT (SOLD SEPARATELY)

  • UP TO 100M OVER CATX / 10KM OVER FIBER

  • ULTRA-LOW LATENCY JPEG2000 COMPRESSION

  • PLUG-AND-PLAY INSTALLATION

  • EDID LEARNING AND MANAGEMENT

  • AV AND IT EXTENSION FOR SECURE ENVIRONMENTS

  • BROADCAST AND PRODUCTION CONTROL ROOMS

  • MILITARY AND GOVERNMENT OPERATIONS

  • MEDICAL AND INDUSTRIAL COMMAND CENTERS

  • DIGITAL SIGNAGE AND WORKSPACE CENTRALIZATION

Video OUT

  • Format: DVI-D Dual-Link Dual-Head, Video Bandwidth Up To 9.9 Gbps per channel

  • Video Resolution: Up To 2560 × 1600 @ 60 Hz (each head)

  • Connector: 2× DVI-D Dual-Link (25-Pin Female)



Other

  • Power: 12 V DC, 3 A (Power Supply Included)

  • Reliability (MTBF): 135,540 Hours (MIL-HDBK-217F (N2) Parts Count Prediction Calculator)

  • Environmental Operating Temperature: 0°C to 45°C (32°F to 113°F)

  • Environmental Operating Humidity: 10% to 90%, non-condensing

  • ESD Protection: Protection per IEC 61000-4-2 Standard at ±30 kV Air and ±30 kV Contact

  • Support Warranty: 1-Year

  • Certification: CE, FCC, RCM, UL

  • Dimensions: 11.5″W × 5.25″D × 1.70″H

  • Weight: 1.81 lbs (0.82 kg)

P2P-KVR302-S

HDMI Transmitter with Single Head support, Point-to-Point mode over CATx & Fiber connection
[Includes: P2P-KVR302, PS5VD2A]
