DPX-XT-TX

DisplayPort, Single-Head, USB 2.0 and audio KVM Transmitter

BECOME A DEALER
  • Extends DisplayPort 1.1 and 1.2, USB 2.0 and audio up to 330 ft (100 m) from the source
  • Supports up to 3840×2160 digital video resolution @ 30Hz
  • Uncrompressed Video
  • Supports keyboard and mouse USB 1.1
  • USB 2.0 Transparent
  • Carries DP, USB 2.0 and Audio Over a Single CAT 5e/6/6a
  • DisplayPort Auxiliary Bypass
  • Plug-and-Play Ready
  • Digital Signage
  • Security
  • PC Networking
  • Conference Center Systems
  • Point of Sale
  • Camera Surveillance
  • Video Phone
  • Control Room Systems
  • Recording Studio
  • PC KVM Extension
VIDEO
Format DisplayPort 1.1 and 1.2
Maximum Pixel Clock 275 MHz
Interface (1) DP female
Resolution Up to 3840 x 2160 @ 30 Hz
DDC via AUX
Input Equalization Automatic
Input Cable Length Up to 15 ft.
Output Cable Length Up to 15 ft.
USB
Signal Type USB 1.1 and USB 2.0
Interface (1) USB Type B (Female)
AUDIO
Frequency 30KHz to 80KHz
Interface (1) 3.5mm (Female)
OTHER
Power External 100-240 VAC/5VDC3A
@ 20 W
Dimensions 5.5” W x 1 7/8” H x 3 1/4” D
Weight 1.0lb per TX/RX unit
Operating Temperature 0-55 °C (32-131°F)
Storage Temperature -20-85 °C (-4-185 °F)
Humidity Up to 95%
PART NO. Description
DPX-XT-TX-S DisplayPort, Single-Head, USB 2.0 and audio KVM Transmitter
Includes: [DPX-XT-TX, (PS5VDC4A)
